AHydraulics Rotary Actuator AHC-115
Product specifications
| Product Attributes | Test method | ||
|---|---|---|---|
| Material | Aluminium | ||
| Drive Torque (kg - m at 210 bar) | 190 | ||
| Holding Torque (kg - m at 210 bar) | 494 | ||
| Cantilever Mount (kg - m) | 700 | ||
| Axial Capacity (kg) | 1,361 | ||
| Displacement 180 degree (cm³) | 505 | ||
| Cylinder Size (Ø) | 115 | ||
Product Description
Ahydraulics Rotary Actuator AHC-115
Related Documentation
For more information, download the documents below
Request the 3D drawing
Working this component into your own design? Request the STEP file and we'll send it straight to your inbox
